Features:
- Designed for 2.4GHz applications: Bluetooth, WIFI(802.11b/g), ZigBee, Wimax(2.3GHz and 2.5GHz) and etc
- High efficiency
- Linear Polarization
- Omni-Directional (PCB dimension dependent)
- No PCB ground clearance required
- Flexible placement on PCB edge
- SMD mounting
- Low profile, minature and light weight
- Tape and reel packaging
- RoHS compliance
Applications:
- tablet_android Tablets
- laptop Laptops
- sensors Sensors
- developer_board Wireless Modules
- directions_car Automotives
Specification
| Model | GAD123432BL04 |
|---|---|
| Frequency | 2.4 - 2.5 GHz |
| S11 | < -10 dB |
| VSWR | < 1.9 : 1 |
| Peak Gain | 2.28 dBi |
| Efficiency | 70% |
| Polarization | Linear |
| Impedance | 50 Ohms |
| Radiation Pattern | Omni-directional |
| Dimension | 12 x 3.4 x 3.2 mm |
| Weight | 0.25g |
| Temperature Range | -25oC to +85oC |
| Humidity | 65oC 95% RH |
Click Here for Product Specification
